Fixed Installation • Fine Pitch

Indoor LED Display Series

From ultra-premium MicroLED for control rooms to cost-effective SMD for large venues. Pixel pitches from P0.5 to P4 covering every indoor application.

11
Pitch Options
P0.5-P4
Range
4
Series
3 Year
Warranty

Viewing Distance Rule

Pitch (mm) × 1.5 = Minimum viewing distance (m)

Example

P1.5 × 1.5 = 2.25m minimum viewing distance

Premium 4K/8K Resolution

UltraFine Series

MicroLED and COB technology for mission-critical environments demanding the highest image quality.

MicroLED / COB
Control RoomsBroadcast StudiosCommand CentersLuxury Retail

Corporate & Commercial Grade

ProFine Series

COB and MiP technology balancing exceptional quality with practical budgets for professional environments.

COB / MiP
BoardroomsCorporate LobbiesMuseumsConference Centers

Retail & Public Spaces

Commercial Series

SMD and MiP technology optimized for high-traffic commercial environments with excellent value.

SMD / MiP
Retail StoresShopping MallsHotel LobbiesShowrooms

Large Indoor Venues

Standard Series

Cost-effective SMD solutions for larger viewing distances in auditoriums and event spaces.

SMD
AuditoriumsHouses of WorshipSports ArenasEvent Halls

Applications

Where indoor LED displays make the biggest impact

Control Rooms

Control Rooms

Mission-critical 24/7 operations

Corporate

Corporate

Boardrooms & lobbies

Retail

Retail

Engaging customer displays

Broadcast

Broadcast

Studio-grade visuals

Catalogue

Indoor LED models (22)

Filter all indoor led

Not sure which model fits? Share the wall size and viewing distance — a specialist will recommend a configuration and send a project quote.

Get a screen recommendation

Buying guide

Choosing an indoor LED screen

Under 1.0 mm pitch

Viewers closer than about 2 m — boardrooms, control rooms, executive suites.

1.0 – 2.0 mm

About 2–4 m — lobbies, meeting rooms, retail feature walls.

2.0 – 4.0 mm

About 4–8 m — showrooms, halls, events and larger retail spaces.

Over 4.0 mm

Beyond about 8 m — large venues and high ceilings.

Rule of thumb only: content type, text size and how close people really stand change the right pitch. We confirm it from your room and content.

What changes the price

  • Pixel pitch — a finer pitch means many more LEDs per square metre.
  • Size and cabinet grid — the screen is built from whole cabinets, so the final size follows the cabinet module.
  • LED packaging — SMD, COB or MiP differ in surface robustness, close-viewing quality and cost.
  • Processing — controllers and video processors for the resolution, inputs and number of sources.
  • Mounting and service access — wall, floor-standing or suspended; front or rear maintenance.
  • Site conditions — wall strength, power, cabling routes and installation hours.
  • Content, CMS and support — who creates and schedules content, and the support you need after handover.

For a first budget, try the budget estimator — it carries your numbers into the enquiry.

What to send for an accurate quote

  • Wall width and height (or a photo with rough measurements)
  • Closest and typical viewing distance
  • What it will show (presentations, video, signage, live feeds)
  • Room lighting and windows
  • Location and timeline

Don't have it all? Send what you know — "not sure" is fine.

Send your project details

Need help selecting the right pixel pitch?

Our technical team provides free specification support based on your viewing distance, content type, and budget.
