corporateFine Pitch LED P1.2
ADNOC HQ — Unified Command Center
Abu Dhabi, UAE 2024 18m x 3m (54 sqm)
Client
ADNOC Group
Consultant
HOK Architects
Contractor
Al Jaber Engineering
The Challenge
The corporate command center required a massive video wall capable of displaying real-time operational data from 40+ sources simultaneously. The display needed 24/7 operation reliability, front serviceability for zero-downtime maintenance, and integration with 6 different data visualization platforms.
Our Solution
A Fine Pitch LED wall at P1.2 was specified for the optimal balance of resolution, reliability, and cost at 3m+ viewing distance. Redundant power supplies and signal processing ensured zero single points of failure. Custom input matrix allowed any source to be displayed at any position and size on the wall.
Results & Impact
Operational response time improved 28% with unified data visualization
Zero unplanned downtime in 18 months of 24/7 operation
Total cost of ownership 45% lower than comparable LCD video wall solution
Maintenance time reduced from 4 hours to 15 minutes with front-service design
Technical Specifications
| Technology | Fine Pitch LED (SMD 4-in-1) |
| Pixel Pitch | P1.2 |
| Total Resolution | 15,000 x 2,500 (37+ megapixels) |
| Brightness | 600 nits (always-on calibrated) |
| Contrast | 8,000:1 |
| Display Size | 18m x 3m (54 sqm) |
| Operation | 24/7 continuous |
| Redundancy | Dual power, dual signal processing |
| Power Consumption | 110 W/sqm average |
| Input Sources | 40+ via custom matrix switcher |
